Neutrally Buoyant Hybrid Communication cable

4X20AWG + 3x2x26AWG (Double Sheath )

CONSTRUCTION DETAILS

4X20AWG Power Cable

3X2X26AWG Date Cable

Pure copper conductor

Polyethylene insulation

Cores twisted in a pair

Foamed PUR Inner Sheath

Underwater PUR Outer Sheath

Kevlar braid strength member

Nominal overall diameter 12.8 mm

ELECTRICAL AND PHYSICAL CHARACTERISTICS

Working voltage 300V

Breaking strength 155 kg

Working load max. 55 kg

Working temperature -30/+80°C

Freshwater buoyancy :Neutral

Buoyancy in salt water :Slightly positive
