Underwater MINI TV cable

Construction characteristics

Coax 75 ohm coax (1 each)

Conductor 1.34 mm² bare copper conductor insulated with PE (1 each)

Shielded twisted pair 0.50 mm² bare copper conductor insulated with PE.

Two conductors twisted together with a tinned copper drain wire and aluminium/polyester foil (1 each)

Shielded twisted pair 1.34 mm² bare copper conductor insulated with PE.

Two conductors twisted  together with a tinned copper drain wire and aluminium/polyester foil (1 each)

Twisted pair 0.22 mm² tinned copper conductor insulated with PE.  Two conductors twisted together (1 each)

Filling compound The cable is filled with cable filling compound

Shield Aluminium/polyester foil and tinned copper drain wire, coverage 100%

Outer jacket Polyurethane jacket. Colour orange
